Colour Wash Lighting, Under Full Control
Most wall washers give you one look, fixed at install. The NLSW-2520 gives you a canvas. Underneath the silicone body sit five separate LED channels — Red, Green, Blue, Cool White and Warm White — each one addressed individually over DMX512, the same protocol used to run theatre rigs, concert stages and hotel show control systems. Set a static warm-white wash on day one, then reprogram the same fixture into a full colour scene for a festival, a brand launch or a seasonal refresh — without touching a single metre of cable.
The 3D-bending silicone body wraps columns, follows curved walls and traces staircase lines, while an IP67 rating means the same fixture that lights a hotel corridor can sit permanently on an outdoor facade. It ships in 5m reels that join end-to-end for long continuous runs, each section patchable into your existing DMX universe.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | NLSW-2520 |
| Profile Size | 25 × 20 mm (silicone body) |
| Input Voltage | 24V DC |
| Power Consumption | 24 W/m |
| LED Density | 36 LED/m |
| LED Type | RGBWW — 5 channel (R · G · B · W · WW) |
| Control Protocol | DMX512 |
| DMX Footprint | 5 channels per address |
| IP Rating | IP67 — dust-tight, waterproof |
| Body Material | Silicone — 3D Bending |
| Reel Length | 5 m, daisy-chainable |
| Driver Sizing | 24W/m × 5m = 120W → use 150W 24V DMX driver |
One Address, Five Channels
This is what your DMX console or Artnet node sees when it patches one NLSW-2520 run — channel 1 through 5 from the start address you assign.
Built for the Outdoors, Not Just the Showroom
The silicone body carries an IP67 rating — dust-tight and rated for temporary submersion — and is UV-stable under continuous sun exposure. That means the same run of NLSW-2520 that lights an indoor lobby wall can be specified for a building facade, an exterior column, or a garden boundary wall with no separate outdoor product line to source. One SKU, indoor and outdoor.
True White When You Need It
The Cool White and Warm White channels are genuine LED emitters, not a red-green-blue blend pretending to be white. Hold the RGB channels at zero and the NLSW-2520 outputs a clean, colour-accurate white wash from roughly 2700K to 6500K — with the full RGB palette still sitting one DMX command away whenever the brief changes from static architectural lighting to a dynamic colour scene.
Key Features
5-Channel Addressing
R, G, B, Cool White and Warm White each sit on their own DMX channel — independent control over colour and white output from one fixture.
DMX512 Protocol
Patches into any professional lighting console, Artnet node or DMX decoder — the same control layer used in theatres and stage production.
3D Bending Silicone
Flexes left-right, up-down and twist — wraps columns, follows curved walls, and traces staircase edges without a rigid channel.
IP67 Outdoor Rated
Dust-tight, waterproof silicone body suitable for permanent installation on exterior facades and wet architectural environments.
24V · 24W/m Output
Delivers a bright, saturated wash even on tall walls and large facade elevations, with predictable driver sizing per run.
End-to-End Daisy-Chain
5m reels join into longer continuous runs — building perimeters and multi-zone installations from a single control line.
Applications
Hotels & Resorts
Lobby feature walls and pool surrounds — scene changes for arrival, dining and evening events
Building Facades
Exterior cladding programmed for brand colours, festival liveries and city skylines
Event Venues
Banquet halls and exhibition spaces with live colour cues from a lighting console
Restaurants & Bars
Walls that shift colour temperature from warm daytime service to vivid evening scenes
Columns & Pillars
Wraps cylindrical columns for 360° colour-washed vertical accents
Landscape & Boundary Walls
IP67 permanent outdoor colour wash for planters, stone walls and garden features
Museums & Galleries
Curated white-light backdrops with the option of colour for temporary exhibitions
Theatres & Auditoriums
Perimeter wash under DMX show control, cued scene-to-scene with the rest of the rig
Frequently Asked Questions
Specify the NLSW-2520 for Your Project
Get pricing, samples, or technical advice on the NLSW-2520 — DMX addressing, driver sizing, universe planning and multi-zone layout for hotels, facades and event spaces.
