Atom-3002R Sleek COB LED Light: small opening, sharp accent
A 45mm cutout, a 24 degree beam and a gun metal reflector give the Atom-3002R the precision of a larger spotlight in a much smaller hole.
When the ceiling has little room to spare
Shallow voids, narrow joinery and tight ceiling grids rule out bulky fittings. The Atom-3002R is built for exactly those conditions: a Ø45mm cutout and a 95mm height.
Behind the small opening sits a 12W Bridgelux COB source with CRI above 90 and a reflector finished in gun metal. The dark reflector keeps the fitting visually calm, so attention goes to the wall, object or surface being lit and not to the light itself.
Trimless or rimless, your call
The Atom-3002R is offered in trimless and rimless versions. Trimless sits flush with the ceiling finish for a seamless plane, while rimless keeps a minimal edge. Choose before the false-ceiling work starts, since trimless needs plaster-in preparation.
Warm or neutral, same optics
Pick 3000K warm white for homes, hotels and restaurants, or 4000K neutral white for retail, offices and showrooms. The 24 degree beam and the build stay the same, so mixed layouts remain consistent.
Key specifications
As listed for the Atom-3002R. Confirm driver and dimming options with Nucleo when ordering.
| Power | 12W |
|---|---|
| Beam angle | 24 degrees |
| Colour temperature | 3000K or 4000K |
| CRI | Above 90 |
| LED | Bridgelux COB |
| Cutout | Ø45mm |
| Height | 95mm |
| Reflector finish | Gun metal |
| Versions | Trimless and rimless |
What the Atom-3002R gives a lighting plan
Practical advantages of a compact, high-CRI COB spot.
45mm cutout
Fits small openings in false ceilings, soffits and joinery where larger spots cannot go.
24 degree beam
A narrow cone lands on the object and leaves the surrounding space quiet.
CRI above 90
Fabrics, timber, skin tones and merchandise keep their true colours.
Bridgelux LED
A recognised COB source for steady output and consistent colour.
Gun metal reflector
A dark reflector reduces visible brightness in the fitting itself.
Trimless and rimless
Two finishes let you match the ceiling detail rather than design around the fitting.
12W output
Enough punch for accent work at normal ceiling heights without oversizing the fitting.
Two colour temperatures
3000K and 4000K options cover homes, hospitality and commercial work.
Where it works best
Spaces where a small, precise, low-glare accent light does the job.
Art and feature walls
Narrow accent on paintings, textured panels and niches.
Living rooms
Accent over consoles, shelves and sculptural pieces.
Hotel corridors and rooms
Rhythmic pools of light along walls and headboards.
Retail displays
True-colour light on merchandise from a discreet fitting.
Jewellery counters
High-CRI sparkle with minimal visible hardware.
Restaurants and bars
Focused light on tables, back-bar shelves and bottles.
Reception areas
Lights logo walls and desks in offices and clinics.
Showrooms
Highlights products in tight ceiling layouts.
Questions, answered
Common planning and ordering questions for the Atom-3002R.
