What Is a Nucleo DIY Fiber Optic Light Kit?
A Nucleo DIY fiber optic light kit is a complete, ready-to-install star ceiling package — the light engine, pre-cut fiber strands, and control remote all in one box. There is no sourcing multiple components separately, no guessing how many fibers to order, and no compatibility issues. Everything is matched, tested, and pre-assembled for installation.
The kit works by bundling all the fiber strands into the 18W RGBW twinkling light engine's input port. The engine generates the light; the fibers carry it individually to each point in your ceiling or panel, creating a natural star field effect. Because no electricity travels through the fibers, the system is completely safe — including for children's rooms, false ceilings, upholstered panels, and similar applications.
Choose Your Kit
Two standard configurations for different ceiling sizes and star field styles. Shooting star and custom options are covered further below.
200-Point Uniform Kit
All 200 fibers are the same diameter — creating a consistent, even star field. Clean and uniform, ideal for minimalist interiors, bedrooms, and modern ceilings.
- 200 × 1mm PMMA fiber strands, 3m length each
- 18W RGBW Twinkling LED Light Engine
- RF remote control
- Power cable
- Installation guide
300-Point Mixed Fiber Kit
Three fiber diameters in one kit — smaller fibers appear as dim distant stars, larger fibers as brighter nearby stars. The most natural-looking star field, closely replicating a real night sky.
- 180 × 0.75mm + 90 × 1mm + 30 × 1.5mm PMMA fibers, 3m each
- 18W RGBW Twinkling LED Light Engine
- RF remote control
- Power cable
- Installation guide
🌠 Shooting Star & Random Twinkling Option
Available as an add-on to both kit configurations. The light engine is upgraded with an internal motorised effect mechanism that creates random twinkling and shooting star sequences across the fiber bundle — no external controller or programming needed.
Specify the shooting star option when ordering either the 200-point or 300-point kit. Also available on all custom kits.
🔧 Fully Custom Kit — Built to Your Specification
Standard kits don't fit every project. Nucleo builds custom fiber optic kits to order — any ceiling size, any fiber count, any length, any engine configuration. Commonly requested for cinema rooms, hotel suites, themed interiors, and oversized ceilings.
To get a custom kit quote, call or WhatsApp Nucleo with your ceiling dimensions, point count estimate, fiber length required, and any special effect or engine requirements.
What Makes Mixed-Fiber Kits Look More Natural
In the night sky, stars vary in brightness — some are intensely bright, most are faint pinpricks. A uniform fiber diameter produces equal-brightness points, which looks clean but artificial up close. The 300-point mixed kit replicates natural star magnitude distribution:
| Fiber Diameter | Points | Visual Effect | Sky Equivalent |
|---|---|---|---|
| 0.75mm | 180 (60%) | Fine, dim points — the majority of the field | Distant / magnitude 4–6 stars |
| 1.00mm | 90 (30%) | Mid-brightness — clearly visible, not dominant | Mid-range / magnitude 2–3 stars |
| 1.50mm | 30 (10%) | Bright accent stars — draw the eye naturally | Bright / magnitude 0–1 stars (Sirius, Vega) |
Technical Specifications
| Specification | Kit 1 — 200 Point | Kit 2 — 300 Point Mixed |
|---|---|---|
| Total Fiber Points | 200 | 300 |
| Fiber Diameter(s) | 1.00mm uniform | 0.75mm (180) · 1.00mm (90) · 1.50mm (30) |
| Fiber Length | 3 metres each | 3 metres each |
| Fiber Type | PMMA End-Emitting (plastic optical fiber) | |
| Light Engine | 18W RGBW Twinkling LED Illuminator | |
| Engine Port Size | 20mm input port | |
| Colour Options | 16M colours (RGBW mixing) + warm white, cool white, colour scenes | |
| Twinkling Effect | Built-in twinkling (standard) · Shooting star add-on available | |
| Control | RF Remote (included) · App control (optional) | |
| Input Voltage | AC 100–240V, 50/60Hz | |
| Ceiling Coverage | ~6–9 sq.m. | ~9–14 sq.m. |
| Recommended Drill Size | 1.2–1.5mm | 1.0mm / 1.2mm / 1.8mm (by fiber type) |
| Warranty | 1 Year (Engine) · Fibers: No moving parts, no wear | |
| Supplied By | Nucleo, Kalbadevi, Mumbai | |
How to Install a Fiber Optic Star Ceiling
No electrician required. The installation involves only the drill, the fibers, and the engine. Every Nucleo kit includes a step-by-step guide.
Plan the Star Layout
Mark random dot positions on the ceiling panel or drywall. Vary spacing naturally — dense clusters and open voids look more authentic than even grids.
Drill the Holes
Drill one hole per star point using the matching drill bit (1.0–1.8mm depending on fiber diameter). Angle holes slightly for the best light spread.
Thread the Fibers
Push one fiber strand through each hole from above. Leave a small stub protruding on the visible side — trim flush after setting.
Bundle & Connect Engine
Gather all fiber ends from above the ceiling into a bundle and insert into the engine's 20mm input port. Secure with the locking collar.
Power Up & Trim
Connect the engine to power. Trim protruding fiber stubs flush with the ceiling surface. Use the RF remote to select colour, brightness, and effects.
Where DIY Fiber Optic Kits Are Used
Master Bedrooms
The classic application. RGBW for sunset oranges and cool midnight blues. Twinkling mode for a calming sleep environment.
Home Cinema Rooms
Star ceiling with shooting star effect for immersive cinema atmosphere. Switch to deep blue during movies, warm white for intermission.
Children's Bedrooms
Safe — no electricity at the ceiling surface, no heat at the fiber ends. Soft twinkling white for nighttime comfort. RGBW for playtime.
Hotel & Resort Suites
Signature ceiling feature for premium rooms. Nucleo supplies matched multiple kits for consistent spec across all suites.
Spas & Wellness
Tunable white fibers for calm, heat-free illumination in treatment rooms. Gentle twinkling for relaxation environments.
Themed & Event Spaces
RGBW shooting star kits for immersive themed interiors, event halls, and experiential retail environments.
Frequently Asked Questions
What is included in a Nucleo DIY fiber optic kit?
Every kit includes the 18W RGBW twinkling light engine, pre-cut PMMA fiber strands at 3-metre lengths (200 or 300 points depending on kit choice), RF remote control, power cable, and installation guide. Everything needed to complete a star ceiling installation is in one box.
What is the difference between the 200-point and 300-point kits?
The 200-point kit uses uniform 1mm fiber throughout — all stars appear at similar brightness, giving a clean, consistent look. The 300-point mixed kit uses three diameters (0.75mm × 180, 1mm × 90, 1.5mm × 30) to create natural variation in star brightness, closely replicating the magnitude distribution of a real night sky.
What is the shooting star option?
The shooting star option upgrades the light engine with a built-in motorised mechanism that creates random twinkling and periodic shooting star streaks across the fiber bundle automatically — no external controller or programming required. Available as an add-on on both the 200-point and 300-point kits, and on all custom kits.
Can I get a custom kit with different points, lengths, or engine configuration?
Yes. Nucleo builds fully custom fiber optic kits to specification — any point count, any fiber length (1m–12m), any fiber diameter mix, and any engine type (Single CCT, CCT tunable, RGBW, DMX, shooting star, dual-port). Contact Nucleo with your ceiling dimensions and requirements for a custom quote.
What ceiling area does each kit cover?
The 200-point kit covers approximately 6–9 sq.m. at a comfortable star density. The 300-point kit covers 9–14 sq.m. For larger ceilings or denser star fields, a custom kit with higher point count is recommended — Nucleo will calculate the correct spec for your room size.
Do I need an electrician to install the kit?
The fiber installation itself (drilling holes, threading fibers, bundling into the engine) requires no licensed electrical work. The light engine plugs into a standard AC wall socket. However, if you need to conceal the engine power cable within the wall or ceiling, a licensed electrician should run a socket to the desired location beforehand.
Where can I buy a Nucleo DIY fiber optic kit in India?
Direct from Nucleo Pan India. Call 08048053614 or WhatsApp +91 8591141102 with your kit choice (200-point / 300-point / custom) and any shooting star add-on requirements. Delivered Pan India.
