"Designed for the architect, interior designer and lighting consultant who needs a strip that performs exactly as specified — no brightness drop, no hotspots, no guesswork. The 2835 24V range is built for cove lighting in five-star hotels, joinery integration in luxury residences, and linear architectural elements in commercial flagship spaces."

The 2835 SMD Chip — Why It Matters for Specification

The SMD 2835 is the workhorse of architectural-grade LED strip lighting. At 2.8 × 3.5mm, it delivers a higher lumen-per-watt efficiency than the smaller 2016 chip while remaining compact enough to achieve 480 LED per metre densities on multi-line configurations. Paired with 24V constant voltage — the professional standard for linear runs — the result is consistent colour temperature, predictable brightness and the run lengths that commercial projects demand. Every strip in this range delivers 24–26 lumens per LED at CRI 80+.

Choosing PCB Width — Matching Strip to Profile

PCB width determines which LED aluminium profile channel the strip will fit, and how far the diffuser sits from the LED surface. Specify width before selecting density or wattage:

3mm
Coin-edge profiles, ultra-narrow slots
5mm
Most recessed & surface profiles
8mm
Medium surface & corner profiles
10mm
Standard cove & wide recessed
15mm
2-line — feature walls, open coves
20mm
3-line — maximum surface brightness

LED Density — Selecting for Uniformity

Higher LED density reduces point spacing, eliminating visible hotspots in diffused outputs. Match density to viewing distance and diffuser depth:

60 LED/m
5W–6W/m
Indirect coves viewed at distance. Deep diffuser channels. Low ambient wash.
120 LED/m
5W–12W/m
Standard cove lighting. Most profile systems. Good uniformity through 10mm+ diffuser depth.
168–180 LED/m
12W–15W/m
Joinery lighting. Mirror surrounds. Tight diffuser channels. High output coves.
240 LED/m
11W–22W/m
Under-shelf display. Premium joinery. Spotless uniformity. E Series high-output option.
360–480 LED/m
23W–26W/m
Multi-line strips. Feature walls. Open-face channels. Maximum surface brightness.
📏

Dropless 20 Metre Roll — No Injection Points

The 10mm 120 LED/m option is available as a Dropless 20 Metre Roll — engineered to maintain consistent brightness across the full 20m length from a single 24V feed. Standard strips require power injection every 5–10m, creating interruptions in long continuous coves. The Dropless roll eliminates this entirely — one driver, one clean run, zero visible brightness variation end to end. Specified for long hotel corridor coves, retail perimeter lighting and large commercial linear applications.

Complete Specification Reference

All strips: 24V DC · SMD 2835 · IP20 · 24–26 lm/LED · CRI 80+

3mm PCB
CodeLED/mPower/mCCT Options
2020-24V1807W
4K, 3K
5mm PCB
CodeLED/mPower/mCCT / Colour Options
2835-24V12010W
5K, 4K, 3K, 27K
2835-24V12010W
RGB + CCT
2025-24V24011W
65K, 4K, 3K
2835-24V16812W
4K, 3K
8mm PCB
CodeLED/mPower/mCCT / Colour Options
2835-24V1205W
3K
2835-24V12010W
65K,5K,4K,3K,35K,27K
2835-24V E SERIES12012W
4K, 3K
2835-24V E SERIES18015W
65K, 4K, 3K
2835-24V606W
65K, 4K, 3K
2835-24V12010W
RGB + RGBCCT
10mm PCB
CodeLED/mPower/mCCT / Colour Options
2835-24V DROPLESS 20M12012W
4K, 3K
2835-24V18015W
65K, 4K, 3K, 27K
2835-24V E SERIES24022W
65K, 4K, 3K
2835-24V24020W
5K,4K,3K,35K,27K
2835-24V24022W
RGB + RGBCCT
15mm PCB (2-Line) & 20mm PCB (3-Line)
CodeConfigLED/mPower/mCCT Options
2835-24V2 Line / 15mm24012W
65K, 4K, 3K
2835-24V2 Line / 15mm48023W
65K, 4K, 3K
2835-24V3 Line / 20mm36026W
4K, 27K

Colour Temperature Range

From human centric 2700K to clinical 6500K — matched to the project's lighting design intent:

2700K
Extra Warm
Luxury / Residential
3000K
Warm White
Hospitality / F&B
3500K
Neutral Warm
High-End Retail
4000K
Natural White
Offices / Showrooms
5000K
Cool White
Galleries / Healthcare
6500K
Daylight
Display / Signage

Tunable White & RGBCCT: Multiple strips in this range support dual-channel tunable white (CCT shift from warm to cool) or full RGBCCT (colour + tunable white from one strip). These are specified for human centric lighting applications — hotel rooms, healthcare, premium offices — where colour temperature changes through the day are part of the design brief.

Specification Advantages

📐
3mm to 20mm PCB
Widest profile compatibility in the range. From coin-edge ultra-narrow slots to open-face multi-line cove panels — one supplier, full coverage.
⚡
24V — Long Run Standard
Up to 10m per channel without power injection. The professional voltage for commercial and hospitality LED linear installations.
🎯
E Series — High Output
Enhanced efficiency E Series variants deliver higher lumen density within the same PCB width — specified when output requirement exceeds what the standard strip achieves.
📏
Dropless 20m Roll
No power injection breaks across 20 metres. Consistent end-to-end brightness for long uninterrupted cove and perimeter runs.
🌈
Full CCT + RGBCCT Range
2700K to 6500K single whites, tunable white, RGB and RGBCCT — covering every project specification from luxury residential to dynamic commercial.
🏅
CRI 80+ Consistent
Minimum CRI 80 across the range. All strips are binned for colour consistency — critical for long profile runs where adjacent strip sections must match.

Typical Project Applications

🏨
Five-Star Hotels
Corridor coves, room perimeter lighting, lobby feature walls, F&B mood lighting systems.
🏠
Luxury Residences
Joinery-integrated lighting, ceiling coves, staircase perimeters, master bedroom HCL systems.
🛍️
Flagship Retail
Display shelf lighting, perimeter coves, product display backlighting, window dressing.
🎨
Art Galleries
Wall grazing, alcove accent lighting, display plinth integration where colour accuracy is paramount.
🏢
Premium Offices
Boardroom perimeter coves, reception feature walls, human centric lighting systems.
🍽️
Upscale Restaurants
Booth perimeter lighting, bar coves, ceiling feature elements, dynamic CCT for dining transitions.
🏥
Healthcare Facilities
Tunable white for circadian rhythm support. Long corridor coves with dropless rolls.
✈️
Airport & Transit
Long perimeter runs, wayfinding coves, lounge ambient systems requiring consistent end-to-end uniformity.

Technical Questions

Why specify 24V over 12V for architectural LED strip installations?
24V allows continuous runs up to 10 metres per channel without voltage drop causing visible brightness variation — compared to approximately 5 metres on 12V. For long coves, perimeter runs and corridor lighting in commercial and hospitality projects, 24V is the professional specification standard. It also reduces current draw, allowing smaller wiring gauge and driver specifications.
How do I choose the right LED density for a project?
LED density determines dot visibility and light uniformity. For applications viewed at close range or through narrow-aperture profiles — under-shelf, joinery, mirror surrounds — specify 180–480 LED/m to eliminate hotspots. For recessed coves viewed indirectly at a distance, 120 LED/m through a 15mm+ diffuser channel often provides excellent uniformity. Always match density to the diffuser channel depth: deeper channels are more forgiving of lower densities.
What is the E Series and when should it be specified?
E Series variants offer higher LED density and wattage on a given PCB width. On 8mm PCB, E Series delivers 12W/m or 15W/m versus the standard 5–10W/m. On 10mm, E Series reaches 22W/m at 240 LED/m. Specify E Series when the design requires maximum lumen output from a specific profile width — for example, a 10mm recessed slot that must deliver the brightness of a much wider strip.
What does 'Dropless 20 Metre Roll' mean?
Standard strips require power injection every 5–10m to prevent visible brightness drop. The Dropless 20m Roll maintains consistent brightness across its full 20m length from a single 24V feed — no injection points, no interruptions in long continuous installations. Ideal for hotel corridor coves, retail perimeters and large linear architectural runs.
What PCB width fits which LED aluminium profile?
3mm fits ultra-narrow coin-edge profiles. 5mm suits the majority of standard recessed and surface profiles. 8mm fits medium surface and corner profiles. 10mm fits standard wide recessed cove channels — the most common hospitality specification. 15mm and 20mm multi-line strips are for open-face channels where maximum surface brightness is needed without a diffuser, typically feature walls and display backlighting panels.
What colour temperature options are available?
Single white: 6500K, 5000K, 4000K, 3500K, 3000K and 2700K. Tunable white (dual-channel CCT) allows dynamic shift between warm and cool white. RGBCCT combines five channels (Red, Green, Blue, Cool White, Warm White) for full colour plus tunable white — the most versatile option for hospitality mood lighting and human centric lighting systems.
